PRODUCT OVERVIEW
Lengths
Up to 15.5m
Width
From 25mm to 190mm
Height
From 200mm to 630mm
Size outside of these parameters are available on request
Further Details
Durability
Class 1
Appearance Grade
A Only
Profiles
Straight of cambered to 600m radius
Curves (see curves tab)
Design Properties | |
---|---|
Glulam Grade | GL10 |
Density | 515 kg/m3 |
Strength [N/MM2] | |
---|---|
Bending | Fm,k = 22 |
Tension | Ft,0,k = 13 (parallel), Ft,90,k = 0.5 (perpendicular) |
Compression | Fc,0,k = 20 (parallel), Fc,90,k = 2.4 (perpendicular) |
Shear | Fv,k = 2.4 |
Stiffness [KN/MM2] | |
---|---|
Mean MOE Parallel | E0,mean = 10 |
5% MOE Parallel | E0,0.5 = 6.7 |
Mean MOE Perpendicular | E90,mean = 0.33 |
Mean Shear Modulus | Gmean = 0.63 |
Lengths
Up to 15.5m
Width
From 25mm to 190mm
Height
From 200mm to 630mm
Size outside of these parameters are available on request
Further Details
Durability
Class 4 (Above Ground)
H2 & H3 treated options
Appearance Grade
A & B
Profiles
Straight of cambered to 600m radius
Curves (see curves tab)
Design Properties | |
---|---|
Glulam Grade | GL10 |
Density | 550 kg/m3 |
Strength | |
---|---|
Bending | Fb = 22MPa |
Tension | Ft = 11MPa |
Compression | Fc = 26MPa |
Shear | Fs = 3.7MPa |
Stiffness | |
---|---|
Modulus of Elasticity | E = 10,000MPa |
Modulus of Rigidity | G = 670MPa |
Lengths
Up to 15.5m
Width
From 25mm to 80mm
Height
From 90mm to 630mm
Size outside of these parameters are available on request
Further Details
Durability
Class 4 (Above Ground)
H2 & H3 treated options
Appearance Grade
A & B
Profiles
Straight of cambered to 600m radius
Curves (see curves tab)
Design Properties | |
---|---|
Glulam Grade | GL10 |
Density | 650 kg/m3 |
Strength | |
---|---|
Bending | Fb = 38MPa |
Tension | Ft = 20MPa |
Compression | Fc = 33MPa |
Shear | Fs = 4.2MPa |
Stiffness | |
---|---|
Modulus of Elasticity | E = 15,000MPa |
Modulus of Rigidity | G = 980MPa |
Lengths
Up to 12m
Width
From 25mm to 280mm
Height
From 35mm to 400mm
Height
From 1200mm
